Choochart Choochaikupt/Getty ImagesIf you drive a hybrid car, you might not be aware that it actually has two batteries: a low-voltage auxiliary battery and the much larger traction battery. What happens when a hybrid battery dies depends on which of those batteries you're having trouble with. The 12-volt battery wakes up the car's computers and runs conventional accessories. The traction battery stores energy for the electric motor and, through a DC-to-DC converter, helps keep the 12-volt system charged. If that small battery is dead, the car may be completely inoperable even when the high-voltage pack is fine.The larger pack should never run completely empty during ordinary driving. In a conventional hybrid, the gasoline engine and regenerative braking recharge it as the car moves. A plug-in hybrid that shows zero electric miles has usually reached the end of its EV-only range, not suffered a battery failure; the vehicle then switches to hybrid operation. If the traction pack deteriorates or develops a fault, the car may keep moving with reduced power, or it may stop and refuse to restart. The outcome depends on the model and the fault. And even though hybrids have a gasoline-powered engine, it's not a spare drivetrain waiting to take over. On many hybrids, the electrical side also starts the engine or provides some of the propulsion needed to move the car. A high-voltage battery warning needs prompt attention.AdvertisementAdvertisementRead more: Are remote car starters still worth it in 2026?What actually happens when a hybrid battery dies?A dead 12-volt battery usually prevents the car from entering its initial READY state. Dim lights, unresponsive locks or a dashboard that will not wake up point toward the auxiliary battery, although those clues are not a diagnosis. Many hybrids can be jump-started at a designated terminal, as Toyota and Honda explain in their manuals. The jump is for the 12-volt system only.A failing traction battery behaves less predictably. The car may show a "Check Hybrid System," "Power System" or manufacturer-specific warning, cut electric assistance, limit acceleration and use more fuel. Overheating can also produce similar symptoms. Honda says an obstructed battery air intake can make the system limit battery output, while Toyota lists blocked cooling vents as one reason for a traction-battery maintenance message. So while a warning light will indicate that there's a problem, it doesn't mean the entire pack needs replacement.More serious faults can shut down the hybrid system or prevent the next start. Toyota warns that continuing to drive after certain traction-battery service messages can eventually leave the hybrid system unable to start. A car that keeps moving after a warning isn't proof that it can drive indefinitely without a functioning pack. A cooling problem, an overheated pack and an internal battery failure are different faults, and hybrid designs do not all respond to them in the same way.What to do about a failed hybrid batteryBluegame/Getty ImagesRead the dashboard message before doing anything else. If it says to stop safely, you'll need to pull over, switch the car off and call roadside assistance. If it asks for service but the car still drives normally, don't treat that as permission for a long trip. The owner's manual gives the model-specific response and towing method. Don't open the traction-battery case or touch orange cables and connectors, as high-voltage work should only be done by trained technicians.AdvertisementAdvertisementIf the symptoms point to the 12-volt battery, use only the jump-start procedure in the manual. Never connect jumper cables to the traction battery, and don't expect a conventional jump to recharge a failed high-voltage pack. Plugging in a plug-in hybrid can restore its normal EV range after ordinary depletion, but it won't repair damaged cells or clear an underlying system fault.The next step is a proper diagnosis, not an automatic battery order. A technician should read the trouble codes and check the pack, cooling system, wiring, sensors and 12-volt charging circuit. The repair may be as simple as clearing a blocked cooling intake, or it may require battery work or replacement. Check the hybrid-component warranty before approving an expensive repair; coverage differs by brand, model year, mileage and location. Toyota's US warranty, for example, covers the traction battery in many 2020-and-newer hybrids for 10 years or 150,000 miles.Battery failure can be expensive, but age alone doesn't prove that a pack is finished. The diagnostic results and warranty, not the warning light alone, should determine the repair.Found this useful? Sign up for Engadget's free newsletter for more tech news and guides delivered straight to your inbox. You can also follow us or add Engadget as a preferred search source on Google.Read the original article on Engadget.
